Designed for lab-scale R&D, this lab high-end functional film continuous biaxial stretching experimental line processes PP, PA, PE, PET films, enabling precise biaxial stretching for packaging, electronics, and medical applications.
Ø Servo -driven extruder screw with stepless precise speed adjustment, ensuring stable plasticization and uniformity
Ø CAE-optimized co-extrusion die geometry featuring streamlined flow channels (zero dead zones) to ensure homogeneous material distribution
Ø Height-adjustable casting roller to accommodate varying melt strengths and optimize casting process requirements.
Ø Independent servo motor drives for all power rollers, enabling precise speed control and excellent synchronization.
Ø Industrial-grade PLC & HMI integration with intuitive touchscreen interface for reliable operation and seamless user interaction
Ø Real-time data acquisition & visualization (pressure, temperature, line speed，etc) for enhanced process monitoring
Ø Ergonomic structural design for enhanced operational convenience.
Ø Optional Configurations
Melt Pump: Enhanced metering accuracy for high-viscosity materials.
Electrostatic adsorber/air knife: Enhances melt adhesion to the roller surface.
Constant-tension or follow-up roller winding device: Improve film winding consistency
Online vision inspection: Detects film defects during continuous production.
Ø Co-extrusion casting experiments for polymer materials
Ø Research and optimization of co-extrusion casting processes
Ø Performance testing of new materials in co-extrusion casting applications
| Product Model | FOCL-06/20 |
| Product Code | FOC-001 |
| Co-extrusion Layers | 5 |
| Screw Diameter | 30 mm |
| Rated Screw Speed | 120 rpm |
| Extruder Temperature Control Range | Room temperature to 350°C |
| Cast Film Thickness | 0.3 mm |
| Cast Film Width | 300 mm |
| Maximum Stretching Temperature | 150°C |
| Longitudinal Stretching Points | 2 |
| Maximum Longitudinal Stretch Ratio | 10 |
| Maximum Longitudinal Outlet Line Speed | 30 m/min |
| Maximum Transverse Stretch Ratio | 8 |
| Transverse Inlet Width | 200-300 mm |
| Transverse Outlet Width | 600-1200 mm |
| Operating Voltage | 3-phase AC 380V ±10%, 50Hz |
